NVR Specification
|
|
|
||
|
|
Model
|
ES-Z0401D-XM-POE
|
||
|
System
|
Processor
|
Hi 3520D V200
|
||
|
Interface
|
Preview
|
1/4
|
||
|
Video
|
Decode
|
H.265
|
||
|
|
Encode ability
|
4*5M 25 fps
|
||
|
|
Input mode
|
4*1080P ; 4*3mp
|
||
|
|
Mobile detection
|
Each screen can be set to 192 (16 * 12) detection areas;
|
||
|
|
|
multi-level sensitivity can be set (Limited local channel)
|
||
|
Record & playback
|
Record mode
|
manual>alarm>motion detection>timing
|
||
|
|
Local Playback
|
1ch(analog input mode)
|
||
|
|
Search mode
|
Search by time, calendar, event, channel
|
||
|
Storage & backup
|
Video storage
|
HDD, network
|
||
|
|
Occupied space
|
1pcs camera/day : 1080P 30G ; 720P 20G ; 960H 12G
|
||
|
|
Backup mode
|
Network; USB hard disk; USB burner; SATA burner
|
||
|
|
Video output
|
1ch VGA, 1ch HDMI
|
||
|
|
|
Output resolution: 1024*768; 1280*1024; 1440*900; 1920*1080
|
||
|
|
Network interface
|
5 * RJ45 10M/100M self-adaption
|
||
|
|
USB
|
2* USB 2.0 ports
|
||
|
|
HDD
|
1*SATA ports (Max 8TB/per)
|
||
|
General
|
Mobile phone
|
Support various mobile monitoring (iPhone, Android);
|
||
|
|
Power supply
|
12V/5A
|
||
|
|
Power Consumption
|
<15W (without HDD)
|
||
|
|
Working environment
|
Temperature:0℃—+55℃; Humidity:10%—90%; Atm:86kpa—106kpa
|
||
|
Camera Specification
|
|
|
||
|
|
Model
|
ES-6672HDE-POE
|
||
|
To configure
|
Processor + sensor
|
XM 510 ISP + H62 1/4" CMOS sensor
|
||
|
|
Low illumination
|
0.01 Lux @ (F1.2,AGC ON),0 Lux with IR
|
||
|
|
Effective pixel
|
HD 1080P /3MP
|
||
|
|
Lens
|
HD lens 3.6MM
|
||
|
|
Infrared lamp
|
8pcs
|
||
|
|
Infrared distance
|
100m (open), 25m (with obstacle)
|
||
|
|
Day&night
|
IR cut filter with auto switch
|
||
|
General
|
setting
|
Saturation, brightness and contrast ;
|
||
|
|
|
are adjustable through IE browser or client software.
|
||
|
|
temperature
|
-10℃-+60℃
|
||
|
|
humidity
|
10%-90% RH
|
||
|
|
Power supply
|
DC12V±10%
|
||
|
|
Consumption
|
MAX 3W
|
||
|
|
Waterproof grade
|
IP66
|
||
|
|
Video compression
|
H.265
|
||
