Description
x5MP AHD CCTV Security Camera System – Professional Surveillance Kit with Night Vision & AI Face Detection
What is the best affordable 5MP CCTV security camera system? The ESOE 5MP AHD Security Camera Kit is a professional-grade, budget-friendly surveillance system designed for homes, offices, warehouses, and retail stores. It features H.265+ video compression for efficient storage, infrared night vision up to 20 meters, and AI-powered face detection for smart alerts. Available in 4-channel, 8-channel, and 16-channel configurations, it supports 5-in-1 hybrid input (AHD/TVI/CVI/CVBS/IP) — making it compatible with most existing analog and IP cameras.
Key Features
- 5MP Ultra HD Resolution – Crystal-clear 2560×1944 video quality for detailed monitoring and evidence capture
- AI Face Detection – Smart alerts triggered by human face recognition, reducing false alarms from animals or weather
- H.265+ Compression – Saves up to 70% storage space compared to H.264, extending HDD recording time significantly
- IR Night Vision – Built-in infrared LEDs provide clear footage up to 20m (65ft) in complete darkness
- 5-in-1 Hybrid DVR – Compatible with AHD, TVI, CVI, CVBS, and IP cameras for maximum flexibility
- Dual Output (HDMI + VGA) – Connect to any monitor or TV for real-time viewing
- Remote Access via Hieasy App – Monitor your property from anywhere using your smartphone (iOS & Android)
- Two-Way Audio – Built-in microphone and speaker for real-time communication
- Multiple Recording Modes – Manual, scheduled, motion-triggered, alarm-based, and smart recording
- IP66 Weatherproof Cameras – Designed for reliable outdoor use in rain, snow, and extreme temperatures
How to Set Up This CCTV Security Camera System
- Mount the cameras – Install the outdoor cameras at desired locations using the included mounting brackets and screws
- Connect to DVR – Run BNC cables from each camera to the DVR recorder (up to 4/8/16 cameras depending on your kit)
- Connect storage – Install a SATA hard drive (not included) into the DVR for local recording
- Power on & configure – Connect the DVR to your monitor via HDMI or VGA, power on, and follow the setup wizard
- Set up remote access – Download the free Hieasy app, scan the QR code on the DVR, and start monitoring remotely
Technical Specifications
| Video Resolution | 5MP (2560×1944) / 2MP (1920×1080) |
| Video Compression | H.265+ / H.265 / H.264 |
| Frame Rate | 5MP @ 12fps / 2MP @ 25fps |
| Video Input Type | 5-in-1: AHD / TVI / CVI / CVBS / IP |
| Channel Options | 4CH / 8CH / 16CH |
| Night Vision Range | Up to 20m (65ft) IR LEDs |
| Video Output | HDMI + VGA simultaneous output |
| Storage | 1x SATA HDD (up to 8TB) + Cloud Storage |
| Smart Features | AI Face Detection, Motion Detection, Smart Recording |
| Audio | Two-Way Audio Supported |
| Remote Access | Hieasy App (iOS & Android) |
| Weather Rating | IP66 Waterproof (Outdoor Cameras) |
| Brand | ESOE |
| Model | ES-AHC-RDU5MP-A |
Product Gallery
Frequently Asked Questions
What is the difference between 2MP and 5MP security cameras?
2MP (1080p) cameras capture video at 1920×1080 resolution, suitable for general surveillance. 5MP cameras record at 2560×1944 resolution — providing 2.5x more detail, making it easier to identify faces, license plates, and small objects at greater distances.
How many cameras do I need for my home?
For a typical home, a 4-channel system covers front door, back door, garage, and one side entrance. For larger properties or businesses, an 8-channel or 16-channel system provides comprehensive coverage.
Does this CCTV system work at night?
Yes. Each camera includes built-in infrared (IR) LEDs that automatically activate in low-light conditions, providing clear footage up to 20 meters (65 feet) in complete darkness.
Can I view my security cameras remotely on my phone?
Yes. Download the free Hieasy app on your iOS or Android smartphone, connect the DVR to your network, and scan the QR code to add the device. View live feeds and receive motion alerts from anywhere.
What hard drive size do I need for continuous recording?
With H.265+ compression, a 1TB hard drive stores approximately 15-20 days from 4 cameras at 5MP. A 4TB drive extends this to 60-80 days. The DVR supports up to 8TB SATA hard drives.
Why Choose This AHD Security Camera System?
Compared to WiFi-only camera systems, this wired AHD system offers:
- More reliable connection – No WiFi interference or signal drops
- Higher resolution at lower cost – 5MP analog cameras cost less than equivalent IP cameras
- Easier installation – Single BNC cable carries both video and power
- Future-proof – 5-in-1 hybrid DVR lets you mix analog and IP cameras as you upgrade
- No subscription fees – Local HDD storage with optional cloud backup, no monthly fees
